Perforation designs
The secret to acoustic comfort with Knauf DANOLINE ceilings lies in the perforation. By punching holes in a gypsumboard, we give the material an ability to absorb sound. And add an aesthetic character to the material, too. The different geometries of the perforation holes define the degree of sound absorption and sound diffusion.
Unity perforations
The series of Unity perforations extend to the edge of the tile. This means that the finished ceiling surfaces appears smooth and unified surface – thus the name Unity. The Unity series offers a range of perforation geometries to cater to your design specifications.
-
Unity 3
Shape: Square holes
Size: 3.5x3.5mm Distance c/c: 8.33mm
Perforation %: 17.2Alpha value (αw): 0.80-0.95
NRC value: 0.80-0.90 -
Unity 4
Shape: Round holes
Size: Ø4mm Distance c/c: 10mm
Perforation %: 12.2Alpha value (αw): 0.70-0.75
NRC value: 0.75-0.80 -
Unity 6
Shape: Round holes
Size: Ø6mm Distance c/c: 15mm
Perforation %: 11.9Alpha value (αw): 0.65-0.70
NRC value: 0.60-0.70 -
Unity 9
Shape: Square holes
Size: 9x9mm Distance c/c: 20mm
Perforation %: 18.9Alpha value (αw): 0.75-0.90
NRC value: 0.80-0.85 -
Unity 8/15/20
Shape: Round holes
Size: Ø8, Ø15, Ø20mm
Perforation %: 10.8Alpha value (αw): 0.55-0.60
NRC value: 0.55
Framed perforations
Our series of framed designs come with different perforation shapes. They are characterized by an unperforated frame around the edge of the tile.
-
Globe
-
Quadril
-
Micro
-
Tangent
100% recyclability
Our acoustic gypsum ceiling and wall tiles are made from the 100% recyclable material, gypsum Our acoustic ceiling and wall tiles deliver a timeless look and robust performance that lasts a lifetime. What’s more, they can be repainted as often as required, with no impact on acoustic performance, and their properties will not diminish for at least 50 years.
