Adit

Product Details

Perforation

Tangent (T)

Edge

Adit, top

Adit, bottom

Adit

Mitred and glued long edges

Highly effective acoustic post-adjustment in existing rooms

Exceptionally fast and easy installation.
Minimum disturbance of the daily activities in the room.
Utmost easy cleaning and maintenance thanks to the foil-covered, robust surface.

Acoustics

See more absorption coefficients under Absorptiondata

SIZE (MODULE)

450 x 2400 x 9.5 mm


Surface

Foil-covered surface with pre-impregnated white paper NCS S0300-N (RAL 9016).

Gloss 10.

Tested for chemical resistance in accordance with DIN 68 861, FIRA BS 3962 and NEMA LD-3-1991.


WEIGHT KG/M²

Tile weight: 8.0
Transportation weight: 11.8
Installed weight: 12.1

Technical Properties

Air purification & Air quality

Active reduction of air polluants thanks to

Cleneo_logo_262px

Cleaneo Technology effectively reduces concentrations of VOC’s like alcohol, aldehydes, ketons and esters as well as unpleasant odours from e.g. food or cigarette smoke



Air purification properties tested according to CEN standards and VDI guidelines by Fraunhof Insistute

for Building Physics





Indoor value: 10 days
Particle emission: low – less than 0.75 mg



Read more about air quality

Robustness

Durable and dirt resistant surface.
Made of robust, glass fibre reinforced material with excellent pressure resistance.
Under normal conditions of use, the product properties are preserved.



Read more about the hardness of the gypsum core

Moisture Resistance

Tested at 90% RH and 30°C.
The product can withstand temperature conditions of up to 50°C.



Read more about moisture resistance

Hygiene

Dust removal by dry duster or vacuum cleaner.
Removal of marks with a damp cloth.
Normal cleaning practice and neutral cleaning solutions.

See more in the maintenance guide



Read more about hygienic surfaces

Installation

Download: Installation guide (PDF)
